M&C SP2200 Heated Probe with Blowback

M&C SP2200 Heated Probe with Blowback

$0.00

SKU:
M&C SP2200
Share:

M&C SP2200 Heated Probe w/Blowback


The M&C SP2200 heated filter and probe with blow-back option is ideal for high particulate source sampling applications.  It comes with an external ceramic filter type S-2K150, filter porosity: 2µm, with electrically heated external filter 0-180°C adjustable by an incorporated thermostat, oven temperature limiter with reset key at +30°C. Tsetting and low temp. alarm with potential free status-alarm contact at -30°C below Tsetting. With calibration-, isolation- and blow-back valve.  It includes a weather protection shield with insulation, a mounting flange: 3″ ANSI, 150lbs. with thread G3/4″i. Sample gas OUT: 1/4″NPTi. Material: SS316, ceramic, Viton.

Part Number
M&C SP2200 Heated Probe w/Blowback
Weight38.101759 lbs
Dimensions25 × 25 × 25 in

No additional documents available for this product
