M&C SP2200 Heated Probe with Blowback

M&C SP2200 Heated Probe with Blowback

$0.00

SKU:
M&C SP2200

M&C SP2200 Heated Probe w/Blowback

The M&C SP2200 heated filter and probe with blow-back option is ideal for high particulate source sampling applications.  It comes with an external ceramic filter type S-2K150, filter porosity: 2µm, with electrically heated external filter 0-180°C adjustable by an incorporated thermostat, oven temperature limiter with reset key at +30°C. Tsetting and low temp. alarm with potential free status-alarm contact at -30°C below Tsetting. With calibration-, isolation- and blow-back valve.  It includes a weather protection shield with insulation, a mounting flange: 3″ ANSI, 150lbs. with thread G3/4″i. Sample gas OUT: 1/4″NPTi. Material: SS316, ceramic, Viton.

Part Number
M&C SP2200 Heated Probe w/Blowback

No additional documents available for this product

CleanAir Engineering provides world-class service, support, and technical expertise alongside every instrument rental. All air monitoring equipment is inspected or calibrated before shipping from one of our four technical centers. Each rental includes additional accessories and components, providing added convenience and reliability to ensure the success of your project. Contact us for more information.
