ECOM B Plus
$0.00
The ecom B Plus portable gas analyzer is an easy to use handheld gas analyzer designed for commercial and industrial combustion monitoring in a variety of applications. It can be fitted with up to 3 gas sensors, measuring O2, CO & NO, plus Stack and Ambient Temperatures, and Stack Pressure & Draft. The ecom-B Plus also calculates CO2, Efficiency, Losses, Excess Air and Oxygen correction 0-20%. The instrument with its aluminum housing and ergonomic handle has been designed for rugged field use. On board data storage allows for up to 300 separate readings. Its integrated thermal quick printer allows for on-the-spot print-outs. The on-board computer has 5 pre-programmed fuel types and can store up to 16. The ecom-B Plus’ sample conditioning system consists of a high flow pump and radiant gas cooler with condensate trap. An automatic shut-off activates when the condensate trap reaches its maximum capacity. Another unique feature of the ecom-B Pl. The ECOM-B Plus is an easy to use handheld gas analyzer designed for commercial and industrial combustion monitoring in a variety of applications. It can be fitted with up to 3 gas sensors, measuring O2, CO & NO, plus Stack /Ambient Temperatures, Stack Pressure & Draft. This gas analyzer also calculates CO2, Efficiency, Losses, Excess Air and Oxygen correction 0- 20%.
Standard Features
- Up to 3 Electrochemical Sensors
- Sensor Options: O2, CO & NO (NOx Calculation)
- Flue Gas, Ambient, & Sensor Temperature Sensors
- CO2, Efficiency, Losses, Excess Air, & O2 Correction Calculations
- 7ft Standard Sample Line (9ft Available)
- Standard 9 Inch Probe (1ft Available)
- Averaging Tests
- CO Purge Pump to Prevent Oversaturation
- Ambient Cooler Sample Conditioner
- Electronically Monitored Condensate Trap
ECOM B Plus Sensors
- O2
- CO
- NO
B+ – up to 3 sensors (O2, CO, NO for calculated NOx) and 1 lpm pump, for basic spot checking and tuning.
