Ferrules

$1.35$42.00

Stainless Steel, PTFE and Graphite Ferrules are available in fractional and metric tube sizes. They are used with a variety of CleanAir instrumentation for applications which may require water, air, steam, natural gas, gasoline, oil, or hydraulic fluid. Designed for high- and low-pressure applications and corrosive environments. Various sizes are now in stock. Call for additional options.

Clear

SKU:
N/A
Share:

Stainless Steel, PTFE and Graphite Ferrules are available in fractional and metric tube sizes. They are used with a variety of CleanAir instrumentation for applications which may require water, air, steam, natural gas, gasoline, oil, or hydraulic fluid. Designed for high- and low-pressure applications and corrosive environments. Various sizes are now in stock. Call for additional options.



Ferrule MaterialTubing O.D. SizePart Number
316 Stainless Steel1/8″0417SF
1/4″0418SF
3/8″0419SF
1/2″0420SF
5/8″0421SF
PTFE1/8″0417TF
1/4″0418TF
3/8″0419TF
1/2″0420TF
5/8″0421TF
10 mm0410TF
Graphite1/8″0417GF
1/4″0418GF
3/8″0419GF
1/2″0420GF
5/8″0421GF
10 mm0410GF



Temperature Ratings

Ferrule MaterialRecommended TemperatureActual Temperature Limit
PTFE450º F512º F
Graphite800º F842º F
316 Stainless Steel1,250º F1,450º F
Weight0.01 lbs
Dimensions.5 × .5 × .5 in
Material

Graphite, PTFE, Stainless Steel

Size

1 1/2", 1 1/4", 1", 1/2", 1/4", 1/8", 10 mm, 3/4", 3/8", 5/8"
