LDARTools phx42

LDARTools phx42

$0.00

The LDARTools phx42 is an extended-range portable FID analyzer, capable of measuring 0-100,000 ppm methane and other hydrocarbons. Bluetooth-Enabled, capable of continuous monitoring with external power and H2 (continuous mode is not intrinsically safe), the phx42 features easily-swappable pumps and filters, quick H2 refills, and half the warm-up time of the TVA2020. When not connected to a power supply, the phx42-8802 is intrinsically safe.

The LDARTools phx42 is an extended-range portable FID analyzer, capable of measuring 0-100,000 ppm methane and other hydrocarbons. Bluetooth-Enabled, capable of continuous monitoring with external power and H2 (continuous mode is not intrinsically safe), the phx42 features easily-swappable pumps and filters, quick H2 refills, and half the warm-up time of the TVA2020. When not connected to a power supply, the phx42-8802 is intrinsically safe. Certifications include:

  • Class I, Division 1, Groups A, B, C, D, T3
  • Class I, Zone 1 AEx db ia IIC T3 Gb
  • CE 2575 Ex II 2G ITS17ATEX202629X
  • Ex db Ib IICT3 Gb IECExETL 17.0055X

Key Features

PUMP THROTTLING AND DEADHEAD DETECTION

Pump throttling maintains a consistent sample flow–particularly when the filter has been partially blocked.

DATA AND ANALYZER FEEDBACK

Log files are recorded every 2 secs, on the mainboard, including battery voltage, high & low pressure H2 levels, ppm, pump power, exhaust pressure and thermocouple temp. SDKs also available for common platforms. Response time(T-90) ~3.5 Seconds.

BATTERY

A state-of-the-art battery has been developed, which extends service life. The warranty has been increased from 90 days to one year.

  • 10 hours H2 run time
  • 10 hours Battery run time

RENTAL INCLUDES

  • Case and battery charger
  • Hydrogen Fill Adapter (Required)

SOFTWARE REQUIREMENTS

Android 5+ for phx App

FILTER DETECTION

phx42 is able to detect if a filter is in place, and will not let you monitor if the filter is missing. Certain conditions apply.

Spec Sheet

CleanAir Engineering provides world-class service, support, and technical expertise alongside every instrument rental. All air monitoring equipment is inspected or calibrated before shipping from one of our four technical centers. Each rental includes additional accessories and components, providing added convenience and reliability to ensure the success of your project. Contact us for more information.
